Alpha
Sole S.A. Solar Energy Systems Company in Greece - ALPHA Solar Water Heating Panels Manufacturer
ALPHA SOLAR WATER HEATER
SOLE S.A . Athens manufactured the first solar water heater in Greece in 1974 and is still designing and developing new, cutting edge water heaters, cooling panels and waters boilers for tomorrow's market.
The European Commission awarded and funded the development of the scientific design of SOLE 's newest integrated solar water heater, the ALPHA .
A L P H A
Because not everything is created equal under the sun.
Why are the ALPHA solar energy systems so special? Simply because:
AESTHETICALLY it is superior to the conventional thermosiphon solar water heaters by combining the solar collector panel and boiler in one unit. It does not harm the environment, has an inclination adjusting system allowing for maximum absorption of the sun's rays during all seasons and an adjusting height of 50cm to 150cm maximum .
EFFICIENCY is 30%
faster
than in the conventional thermosiphon systems of the same capacity due to the integrated boiler and solar collector panel.
QUALITY is guaranteed as is for all ‘SOLE’ products. It has an ABS casing on the exterior and glazing,
glass coated steel, oven-treated at 840 C o with polyurethane insulation in the interior, plus increased electrolysis protection with magnesium. It will never rust or corrode during its lifetime.
INSTALLATION is simple. No special skills or training are required, even the homeowner can install this solar water heater. Simply place the solar water heater on the roof and connect it to the water supply pipe and hot water outlet pipe. It can also be connected with the electricity mains, if desired.
CREATIVITY in application is unlimited.
ALPHA solar energy systems are ideal for apartment buildings, hotels, factories and any other large structures, by installing as many as needed, side by side. This will eliminate the need for central boilers, pumps, automation, etc.
SMART DESIGNING standardization of materials and contemporary production methods have resulted in the ALPHA's very competitive price.
|
SOLAR ENERGY does not pollute the environment - the ALPHA Integrated Solar Water Heater does not pollute the environment aesthetically either.
In short, the award winning ALPHA integrated solar water heater is an attractive, more efficient, high quality, well-designed, easy to install, energy saving system, which allows for creativity in its application and has a very competitive price.
TECHNICAL SPECIFICATIONS
- Double or single glazing with a layer of static air 15 mm thick.
- Aluminium strip sealed with EPDM rubber.
- Fins that collect & transfer energy or a parabolic concentrating mirror.
- 3mm thick steel collectors-boilers, glass coated, oven-treated at 840 C o . Magnesium anode protection.
- 30-50mm foamed polyurethane insulation. ABS plastic casing, 2.5mm thick, with a UV stabilizer.
- Electric heating element 4KW with double action thermostat. (Back up heating available).
- Transparent insulation membrane (optional).
AVAILABLE SIZES OF ALPHA SOLAR ENERGY SYSTEMS
200 lt
|
